Description
Comply with RoHS 6 Yes
Control 802.3x Flow
Dimensions 280 x 125 x 44 mm
Discharge Air Discharge 8KV
Contact Discharge 4kV
Energy Efficiency Ethernet (EEE) Yes
FAN Fanless
Head-of-line (HOL) Blocking Prevention Yes
Humidity Operating: 0% – 95% RH
Storage: 0% – 95% RH
Interfaces 16 x 1000Base-T
Auto MDI/MDIX
Jumbo Frame 10,000 Bytes
MAC Address Table Size 8192
Maximum Forwarding Rate 23.81Mpps
Maximum Heat Dissipation 34.3 BTU/h
Maximum Power Consumption 10.07W
MTBF 1,882,372 hours
Packet Buffer Size 512KBytes
Power Input AC:100 ~ 240 V
Power Saving By Cable Length
By Link Status
Protection Surge/Lightning Protection (AC Power Inet) : 1kV
Surge/Lightning Protection (All Ethernet Ports) : 1kV
Standby Power Consumption 3.02W
Store & Forwarding Forwading Yes
Switching Capacity 32 Gbps
Temperature Operating: 0 ~ 40 °C
Storage: -10 – 70 ˚C
Weight 1.023 kgs
